Stamping Robot specifically engineered for high-throughput press and stamping environments, guaranteeing complete automation, extreme precision, and high speed to maximize efficiency and reduce cycle time on production lines.
Stamping Robot
BKSKU-JULR-651
6 people
Superior Speed and Precision: The PRPR design ensures very fast cycle times with high repeatability, significantly boosting the parts-per-minute rate.
Flexible Motion (PRPR): Combines the high reliability of linear motion with the ability to precisely orient and rotate the component inside the press, making it ideal for complex component geometries.
Safe and Reliable Handling: Equipped with a specialized Suction Gripper engineered for secure and rapid pickup of metal components without causing scratches or damage.
Compact Footprint: Despite its high capacity, the robot is designed with a small base to maximize available space within the confined press environment.
Easy Integration and Programming: An advanced control system simplifies programming and ensures seamless integration with the press control system or the entire production line.
Low Maintenance: Utilization of high-quality linear components guarantees minimal maintenance requirements and a long operational lifespan.
Robot Type: PRPR - Specialized Stamping/Press Tending Robot.
Axes of Motion: 4 Axes (2 Linear/Prismatic, 2 Rotary/Revolute).
Max. Payload: 5 - 20 kg (Varies by model configuration).
Horizontal Reach (X-Axis): 1500 mm to 3000 mm.
Vertical Stroke (Z-Axis): 800 mm to 1500 mm.
Maximum Speed: Up to 2 m/s (Horizontal axis).
Repeatability: Excellent precision with $\pm 0.05$ mm.
Drive System: Reliable AC Servo Motor Driven for dynamic performance.
End-Effector: Suction Gripper (Customizable for various part geometries).
Protection Rating: IP54 or Higher (Suitable for industrial environments).
